Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth

Guangzhou Viking Auto Parts Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth from wholesalers

    Buy cheap Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth from wholesalers
    • Buy cheap Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth from wholesalers
    • Buy cheap Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth from wholesalers

    Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth

    Ask Lasest Price
    Brand Name : VKNTECH
    Certification : IATF16949/ISO9000
    Supply Ability : 2000000pcs/Year
    Price : $1.00 - $50.00/Pieces
    Model Number : 1K9073
    • Product Details
    • Company Profile

    Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth

    Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth




    OEM Numbers


    FirestoneW01-358-9073HENDRICKSON TRAILERS7193
    1T15AA-3RIDEWELL1003589073C
    1T15S-6SAF Holland57009073
    Goodyear1R11-018KENWORTHK-102-A
    1R11051
    1R12028



    Product Drawing


    Firestone Reversible Sleeve Air Spring, 9.45 X 6.40, Truck Part No. W01-358-9073 For HENDRICKSON TRAILER And Kenwoth


    Specification


    Air Spring Compressed Height6.4 in.
    Air Spring Type1T Reversible Sleeve
    Diameter9.12 in.
    Maximum Height16.9 in.
    Piston Height4.57 in.
    Bead Plate Top Diameter9 in.
    Top Mountstud
    Bottom Stud Configuration2
    Bottom Mountstud
    Top Stud Configuration2
    Bead Plate Bottom Diameter9.45 in.
    ApplicationRidewell 1003589073CREPLACEMENT PISTON COMESWITHOUT STUDS
    Assembled Product Weight (lb)13.6
    Bellows1T15LP-3
    Design Height (in.)11-12.5
    Loading Capacity at 20 psig1,090 lbsf
    Loading Capacity at 60 psig3,270 lbsf
    Loading Capacity at 90 psig4,905 lbsf
    Maximum Diameter10.8
    Maximum Rebound Height (in.)16.95
    Minimum Jounce Height (in.)6.4
    Natural FrequencyHz
    Operating Temperature (Deg C)57 to -54

    Interchanges & Equivalent parts:


    K-102-A, ARB1R11-051, FSIW013589073, 3040-W013589073, 6336212, B7193, TWDW013589073, W013589073, 630045, FI W01 358 9073, S-7193, 0990671, 63-0067, 352-9073, 1R11-051
